A13B-0196-B031-LCD is a direct replacement for Fanuc A13B-0196-B031 (Fanuc Series 180i-MB). A13B-0196-B031-LCD has a much better image quality and is much brighter than old A13B-0196-B031. Wider viewing angle and faster response time then old A13B-0196-B031. A13B-0196-B031-LCD has upgraded our A13B-0196-B031-LEDKIT and A13B-0196-B031-LCD will last 10X longer than CCFL lamps.
A wire adapter is included. No technical skills required! No soldering required! It is easy to Install! Anyone can do it! 1 year warranty.
Installation takes about 15 minutes.
Disconnect CCFL lamp wire harness from inverter board
Disconnect Screen wire harness on A13B-0196-B031
Remove old A13B-0196-B031
Mount A13B-0196-B031-LCD back to the same location
Connect Screen wire harness to A13B-0196-B031-LCD
Connect existing inverter wire harness to the wire adapter
A13B-0196-B031-LCD has the same interface connector, dimension and screw hole as the old A13B-0196-B031.
A13B-0196-B031-LCD included the following items:
1) One LCD screen ( it has upgraded to our Sunlight Readable LED kit)
1) MS456UB LED driver
1) A wire adapter
