12.1" Sunlight Readable 3M 5 wire touch, 1200 nits, P/N: MS121RSBLCDKIT1200T

Roll over image to zoom in

12.1" Sunlight Readable 3M 5 wire touch, 1200 nits, P/N: MS121RSBLCDKIT1200T

moniserv

New MS121RSBLCDKIT1200T Sunlight Readable LCD kit is designed to be used on outdoor environment. With our proprietary LED upgrade kit installed, It is so bright that the contents on display visible under strong sunlight (1200 nits). We bundle it with DVI and VGA input board, please click the drop down list to see other type of input. It is easy to install. Anyone can do it!

You also have an option to choose other type of controller board on right side:

MS121RSBLCDKIT1200 kit included the following items:

12.1 inch New LCD, upgraded to Sunlight Readable SB LED Kit (800X600)

New 3M 17-8581-217 (alias P/N 32525-FAB) 5 wire Resistive touch Screen kit

MS460LC LCD Controller (or MS489LC)

MS610UB LED Driver with wire harness

5 Buttons Key PCB and Wire Harness

Screen Wire Harness

LCD Controller Specifications:

Input source: DVI and VGA (or HDMI, DVI and VGA)

Accept 12V DC Input

OSD: Chinese, English, French, Italian, German, Korean. Russian, Spanish

Key Functions: On/Off, Menu, Auto, +, -(5 Buttons)

Compact Size: 110mm(L)X55mm(W)X15mm(H)

Automatically synchronizes to most industry standard modes.

Automatic image scaling and contrast enhancement.

AC-DC Adapter is NOT included.

LCD Specifications:

Item	Unit	Specifications (C16)
Screen Size	[inch]	12.1
Native Resolution		800 X 600
Active Area	[mm]	246.0(H) X 184.5(V)
Outline dimension	[mm]	276.0(W) X 209.0(H) x 11.0(D)
Bolt Hole Dimension	[mm]	181.3 X 181.3
Input Voltage VDD	[Volt]	3.3/5.0V
Screen Wire Harness		DF14-20P-1LVDS
Electrical Interface		LVDS (6-bit)
White Luminance	[cd/m2]	1200
Contrast Ratio		1500:1
BackLight Connector		BHSR-02VS-1X1
Backlight Inverter		MS610UB
Response time, Rising	msec	6
Response time, Falling	msec	19
Viewing Angle - Horizontal	degree	80
Viewing Angle - Vertical	degree	80
