121PW02F, New Substitute for NEC LED Driver


Price:
$99.99

Description

SHR-08V-S_50MAMS610UB1R+MS534EXT is a new substitute LED driver for NEC 121PW02F. 90 days warranty, It included two wire adapters. Just plug and play!
150PW02F, one of the most popular LED driver that uses in 15 inch NEC LCD screens that are originally equipped with its manufacturer's LED strip. NEC 121PW02F is designed to driver up to 6 LED strings. 121PW02F has 8 pin Molex input connector (53261-0871, 1.0mm) and 12 pin output connector (SM12B-SRSS-TB)
Input: 12V DC
Output: 24V DC Typ
Our Current: 50 ma each string
fPWM: 100 ~ 500 Hz
Compatible with the following Manufacturers and Models:
Manufacture Size LCD Screen
NEC 12.1" NL8060BC31-47
NEC 12.1" NL8060BC31-47D
