G104SN02-V2, 10.4 inch AUO LCD Screen


Price:
$219.99

Description

Refurbished (like new condition) AUO G104SN02-V2 LCD Screen. 90 days warranty.
AUO G104SN02-V2 , one of the most popular LCD screens in control industrial and medical applications. This 10.4 inch G104SN02-V2 is originally equipped with its manufacturer's LED backlight strip with built-in LED driver, which has typically 400 nits (based on its datasheet). By upgrading to our SB44220LED21652R+MS640EXT LED kit, it can reach 1500 nits or higher.
MS640EXT wire adapter is included. No technical skills required! No soldering required! It is easy to Install! Anyone can do it! 90 days warranty.
LED Upgrade kit for AUO G104SN02-V2 , is Listed below
General Specifications:
Item Unit Specifications
Screen Size [inch] 10.4
Native Resolution 800 X 600
Active Area [mm] 211.2(H) X 158.4 (V)
Outline dimension [mm] 243.0(W) X 184.0(H) X 8.0(D)
Bolt Hole Dimension [mm] 132.6 X 166.6
Input Voltage VDD [Volt] 3.3V
Screen Wire Harness DF19-20P-1LVDS- 121W
Electrical Interface LVDS (6-bit), P20: 6 Bit=O/NC, 8 Bit=H(3.3V)
White Luminance [cd/m2] 400
Contrast Ratio 700
BackLight Connector H208K-P05N-02B, 1.25mm 5P(MS542EXT)
Backlight Inverter P1=+12V, P2=GND, P3=ENA, P4=PWM, P5=N/C
Response time, Rising msec 10
Response time, Falling msec 20
Viewing Angle - Horizontal degree 80
Viewing Angle - Vertical degree 80
LCD controller kit DF19-20P-1LVDS-121W_800X600-6Bit
LED Backlight kit SB44220LED21652R+MS640EXT
