T-55532D104J-LW-A-AAN 10.4 inch OPTREX LCD screen


Price:
$209.99

Description

This refurbished OPTREX T-55532D104J-LW-A-AAN LCD screen has been replaced with new polarize film and there are no scratches and no pressure marks on the screens. 30 days money back guaranteed! Like new conditions ! 90 days warranty
OPTREX T-55532D104J-LW-A-AAN, one of the most popular LCD screens in control industrial and medical applications. This 10.4 inch OPTREX T-55532D104J-LW-A-AAN is originally equipped with its manufacturer's LED back light strip with built-in LED driver, which has typically 800 nits (based on its datasheet). By upgrading to our LSR2306511LED212RR LED kit, it can reach 1500 nits or higher.
Six pin pigtail connector is included. It is easy to Install! Anyone can do it!
LED upgrade kit for OPTREX T-55532D104J-LW-A-AAN is Listed below
General Specifications:
Item Unit Specifications (C7)
Screen Size [inch] 10.4
Native Resolution 640 X 480
Active Area [mm] 211.2(H) X 158.4(V)
Outline dimension [mm] 241.0(W) X 180.2(H) X 10.5(D)
Bolt Hole Dimension [mm] 132.6 X 166.6
Input Voltage VDD [Volt] 3.3V
Screen Wire Harness TTL-DF9-31-2829
Electrical Interface TTL
White Luminance [cd/m2] 800
Contrast Ratio 700:1
BackLight Connector SHLP-06V-S-B, 6p 1.0mm (MS574EXT)
Backlight Inverter 27V/120ma/2 strings
Response time, Rising msec N/A
Response time, Falling msec N/A
Viewing Angle - Horizontal degree 70
Viewing Angle - Vertical degree 80
LCD controller kit TTL-DF9-31_640X480
LED Backlight kit LSR2306511LED212RR
